Brick Wall Eight-Outlet Audio Surge Protector

Brick Wall
Item #: PW8R15AUD
Availability: In Stock
Usually ships In 1-2 Business Days
Price: $259.00


    There are no reviews yet.
    Write a review
    • Made in the USA
    • 6' grounded 3-wire #14 SJT line cord, right angle plug.
    • Two unswitched grounded outlets.
    • Six switched grounded outlets.
    • Magnetic shielding steel cabinet: Black.
    • Self-test circuit with visual indicator.

    The 8R family of products represents another evolution of the Brick Wall Surge Filter. Refinements include better shielding, silent operation, a right angle plug and improved appearance. The product also now comes with two additional "fixed" (always on) outlets for use with amplifiers, DVRs, tuners etc.

    For the audiophile and/or home theater enthusiast, we have included receptacles isolated by duplex to help prevent the "cross talk" between digital and analog components.

    This is an excellent unit for protection your home theater or audio system; from your HDTV to your DVR to your amplifier.

    And of course as a surge suppressor/line filter, both in its endurance and performance capabilities, Brick Wall Surge Filter still sets the world's standard. There is no better powerline protection product available today.

    Outlets Available8 isolated by duplex (6 switched, 2 unswitched)
    Load Ratings15A at 120 volts, single phase, 50-60 Hz; full load regulation 1%.
    Receptacle IsolationLow pass filter isolation assures >40db load to load isolation for EFT bursts.
    Endurance Test1,000 surges of 6,000 volts, 3,000 amperes, SRV <400 volts, no failures, L-N (ground wire protection) mode, U.S. Gov't. Mode 1.
    LimitersSeries surge reactor current limiter; cascaded, auto-tracking dual polarity voltage limiters; dual pulse inverters. Parameters optimized for switch-mode power supply protection.
    Clamping Voltage Onset172 volts nominal; 2 volts above peak line voltage (auto-tracking).
    EMI/RFI Filter Response(bi-directional, wave tracking): With 50 ohm Rg load: 3db at 5kHz; 26dB at 100kHz; 38dB at 300kHz.
    Let-Through Slew Rate5,000 volt/µs disturbance reduced to 28v/µs within AC power wave envelope, and less than 10v/µs outside the power wave envelope.
    Maximum Applied Surge Pulse Joule RatingUnlimited rating (due to surge current limiting) (8x20µs).
    Maximum Applied Surge Pulse Voltage6,000 volts (1.2 x 50µs) (Industry Standard rating).
    Maximum Applied Surge Pulse Current>100,000 amperes (unlimited due to current limiting) (8 x 20µs).
    Endurance, C62.41-1991 (formerly IEEE 587) Category B3 (C1) pulses2kv>100,000; 4kv>10,000; 6kv>1,000 (NRTL verified).
    Dimensions3.9" H x 8.3" W x 4.0" D
    Weight8 lbs.
