| Outlets Available | 2 (unswitched) |
| Load Ratings | 15A at 120 volts, single phase, 50-60 Hz; full load regulation 1%. |
| Endurance Test | 1,000 surges of 6,000 volts, 3,000 amperes, SRV <400 volts, no failures, L-N (ground wire protection) mode, U.S. Gov't. Mode 1. |
| Limiters | Series surge reactor current limiter; cascaded, auto-tracking dual polarity voltage limiters; dual pulse inverters. Parameters optimized for switch-mode power supply protection. |
| Clamping Voltage Onset | 172 volts nominal; 2 volts above peak line voltage (auto-tracking). |
| EMI/RFI Filter Response | (bi-directional, wave tracking): With 50 ohm Rg load: 3db at 5kHz; 26dB at 100kHz; 38dB at 300kHz. |
| Let-Through Slew Rate | 5,000 volt/µs disturbance reduced to 28v/µs within AC power wave envelope, and less than 10v/µs outside the power wave envelope. |
| Maximum Applied Surge Pulse Joule Rating | Unlimited rating (due to surge current limiting) (8x20µs). |
| Maximum Applied Surge Pulse Voltage | 6,000 volts (1.2 x 50µs) (Industry Standard rating). |
| Maximum Applied Surge Pulse Current | >100,000 amperes (unlimited due to current limiting) (8 x 20µs). |
| Endurance, C62.41-1991 (formerly IEEE 587) Category B3 (C1) pulses | 2kv>100,000; 4kv>10,000; 6kv>1,000 (NRTL verified). |
| Dimensions | 3" H x 8.5" W x 4" D |
| Weight | 7 lbs. |
